移门雕刻机“大选”竞争原则

1:规格上的比较
Comparison of 1: specifications
对于雕刻机和雕铣机之间规格的区别，直观上可以通过幅面进行区分，雕刻机的幅面比较小，其使用的雕刻刀具较长，长度约在15.9cm，直径为4.35mm左右，雕刻一次进刀深度约在1mm－ 3mm左右；而雕铣机的幅面则比较大，可供选用的刀具直径规格从1mm－16mm，其刀具长度为50-80mm，一次进刀量可达20mm－30mm。相较而言，雕机的规格还是比雕铣机小，这需要根据移门厂家实际需求进行选择。
The difference between the specifications of the engraving machine and the carving machine can be distinguished directly by the amplitude. The engraving machine has a relatively small amplitude. The carving cutter used is longer, the length is about 15.9cm, the diameter is about 4.35mm, the carving depth is about 1mm 3mm, and the width of the carving and milling machine is larger, which can be used for selection. The tool diameter specification is from 1 mm to 16 mm, and its tool length is 50-80mm. The feed rate can reach 20 mm to 30 mm at a time. In comparison, the size of the carving machine is smaller than that of the engraving and milling machine, which needs to be chosen according to the actual needs of the manufacturers.
2:性能上的比较
Comparison of 2: performance

从产品性能上来看，雕刻机设计轻巧，X、Y轴移动速度快，Z轴行程较短，雕刻主轴头装有弹簧压鼻，作用是在雕刻过程中压平3mm以下的薄板材，主轴还可通过皮带连接到直径较大的马达上，以此使转速增大，这样雕刻出来的工件质量就较为光滑；雕铣机运行时可灵活使用，装细刀干细活，装粗刀干大活。由于机器设计注重重型负载，机架钢性大，Z轴行程大，性能也较优。不过这同样也是按需挑选的，因为适合的才是的。

From the product performance, the design of the engraving machine is light, the X, Y axis moves fast, the Z axis is short, the spindle head is equipped with a spring nose, the function is to press the thin plate below the 3mm in the carving process, and the spindle can also be connected to the larger diameter motor by the belt, in order to make the rotational speed increase and the engraving work will increase. The quality of the workpiece is smoother, and the engraving and milling machine can be used flexibly when it runs, with fine knives and fine work, and heavy knives. Because the machine design pays attention to heavy load, the frame has large steel structure, large Z axis stroke and excellent performance. But it is also chosen on demand, because the best is the right one.
3:用途上的比较
Comparison of the use of 3:
若是从产品的用途进行比较，雕刻机主要是用于对板材的雕刻，适合雕刻5mm－8mm的材料，在标志、标牌方面应用较为普遍，由于设计方面的限制，它适合做切削量很小的高转速的雕刻工艺制作；而雕铣机可以理解为既可做精细雕刻，又能做切割、镂铣，一次进刀量相当大的，如200mm宽材料可一次完成，因此不仅可以做小型雕刻机的工艺，更可高速切割厚的板材，这是雕刻机根本做不到的工艺制造。若是移门厂家对雕刻的速度和灵活度要求比较高的话，则可选择雕铣机。
If compared with the use of the product, the engraving machine is mainly used for the carving of plate, suitable for engraving the material of 5 mm - 8 mm. It is more common in signs and signs. Because of the limitation of design, it is suitable for making high speed carving process with very small cutting quantity; and the carving and milling machine can be understood as fine and fine. Carving, and can do cutting, cutting and milling, a large amount of knife, such as 200mm wide material can be completed once, so not only can do small carving machine technology, but also high speed cutting thick plate, this is the carving machine can not do the process of manufacturing. If the door shifting manufacturers require higher engraving speed and flexibility, they can choose the engraving and milling machine.
